Min quantity:1Piece
Quantity:999Piece
Deliver:In 7 days
Overview
Essential details
Applicable Industries:
Manufacturing Plant
Showroom Location:
Saudi Arabia, Indonesia, Pakistan, India
Condition:
New
Type:
Die-cutting Machine
Computerized:
Yes
Place of Origin:
Zhejiang, China
Brand Name:
WITY
Voltage:
220V/1P
Dimension(L*W*H):
2600x950x1400kg
Weight:
1700kg
Warranty:
1 Year
Production Capacity:
300 m/min
Key Selling Points:
High Productivity
Max. workable width:
320mm
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Marketing Type:
Ordinary Product
Warranty of core components:
1 Year
Core Components:
Motor
PLC Brand:
N/A
Machine Type:
label die cutter
Max speed:
300times/min
Max unwinding diameter:
500mm
Max web width:
320mm
Max die-cut width:
300mm
Max die-cut length:
300mm
Position accuracy:
±0.1mm
After Warranty Service:
Video technical support, online support, Spare parts, Field maintenance and repair service
Local Service Location:
Saudi Arabia, Indonesia, Pakistan, India
After-sales Service Provided:
Free spare parts, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, online support
Certification:
CE
Supply Ability
Supply Ability
30 Set/Sets per Month
Packaging & delivery
Packaging Details
standard wooden package for export
Port
Shanghai or Ningbo
Lead time:
Quantity(sets) 1 - 1 >1 Lead time (days) 35 To be negotiated
Video Description
1. Description:
1) It is adopts micro-computer control for accurate flatten die cutting, material feeding, and sheeting, 3 points photocells for web-guiding and tracking.
2) Die cutting, waste collecting and finished-material sheeting or rewinding are on one process.
3) The machine could be used for die cut adhesive paper, dacron label and laser hologram label.
4) It is the ideal auxiliary equipment of flexo printing machine, silk screen printing machine, gravure printing machine and hologram mark printing machine, and the most efficient unit for printing house.
2. Main Equipments:
a) Servo Motors are equipped for accurate material transmission.
b) Touch Screen for convenient operation
c) Frequency Converter used for speed regulation
d) 3 pcs of Photocells are used for web guiding
e) Lamination shaft, sheeter device, rewinder are equipped for multi purpose.
3. Optional Parts:
a) Punching device;
b) Hot-stamping device;
c) Laminating device
Inline slitting and rewinding function (option)
4. Main Technical Specification:
Model | 320G model | 420 model |
cut speed | 20-170 strokes/min | 20-170 strokes/min |
Max unwinding diameter | 500mm | 500mm |
Max web width | 320mm | 450mm |
Max die-cut width | 300mm | 400mm |
Max die-cut Length | 300mm | 400mm |
Position accuracy | ±0.1mm | ±0.1mm |
Total power | 3.5kw | 4.5kw |
Power vole | 220v±10% | 380v±10% |
Machine weight | about 1700kg | about 2300kg |
Overall dimension | 2.6(L)×0.95(W)×1.4(H)(m) | 2.7(L)×1.05(W)×1.5(H)(m) |
